contact>>date：2017-08-08 10:31
u402 is a WiFi timer switch which controls power ON/OFF of a timer switch. It can be used to control electronic equipments which are required ON/OFF automatically. Customers settings available for multiple delay ON/OFF time groups to control the equipments.
With L & N line inputs and good for any kinds of devices;
There are up to 20 timer settings during each day;
With accurate timer settings to the second. On and Off time can set at any time during 24 hours;
Manual control and automatic control are available. After the timer is set the switch will work automatically. When the system is working the user can manually turn on or turn off the load;
LCD display shows the preset time when setting the timer and shows current time and the latest on/off time after the setting;
Smartphone direct control or front panel button control optional;
Uses flame resistance ABS-V0 material for safety; and
Classical 86 series design and easy installation.
1. Download an Android APK and launch the program. A password matching the WiFi Timer Switch u402 needs to be entered for the first sign-in.
2. Once the password is confirmed and gain access to the load type selection interface click to select the right load type to be controlled.
3. Once load type is selected and enters the control interface click the icon to control the load.
Once switch on an u402 WiFi Timer Switch home appliances or other electronic equipments are not only controllable by a Smartphone but also can have their operation status displayed by a smart phone. u402 WiFi Timer Switch can control many kinds of appliances such as school and barracks’ bells household curtain motors or street lights. And it can be used in hospital kindergarten or restaurant’s ultraviolet disinfection rooms farm’s brooder houses or fish tank. Fig. 4 shows typical applications of u402 WiFi Timer Switch.
